Great new information sources I learned

Dear HPN Community,

Hope you all think that abouthpnetworking.com is providing good information. But there is always more . . .

Today I learned some great new information sources from my colleague Chris Young.

First web site is:
http://www.wookieware.com/

This site provides two great auto configuration generation tools. One is for IRF and other one for HP 830 wireless controllers. The author of this site is also programmer behind tool named glarn. Glarn is part of HPN SDN App Store.

The second web site is:
http://www.netopscommunity.net/home

This web site provides full focus on HP IMC. The site provides forums but also github with scripts and adapters for third party products. Really valuable information.

Would be great if everyone can share his/her great information sources!

Regards, Dobias
@networkingdvi (Twitter)

Posted in Uncategorized | Leave a comment

Comware IRF: L2 MAC Address roaming

IRF is used on Comware switches (and some routers as well now) to virtualize 2 or more devices as 1 virtual device.

This is a very convenient way to simplify the network setup and management. Although IRF is very easy in the daily use, we should not forget that it actually runs on multiple physical switches, so the under the hood, multiple switch ASICs and forwarding tables have to be kept in sync.

This post covers a scenario where IRF needs some additional configuration in order to make sure it still behaves as “1” switch. Continue reading

Posted in Comware5, Comware7, IRF | Tagged , , | 13 Comments

Unified wireless: AP template rename

On the Unified Wireless controllers, it is common to enable the auto-ap and auto-persistent features to make it easy to adopt new Access Points.

The new APs will be discovered and auto-registered as AP template based on the AP MAC Address. It is easier if the AP can be given a more user-friendly name.

This post shows how an existing AP template can be renamed.

Continue reading

Posted in Unified Wireless | Tagged | Leave a comment

Unified wireless : AP console/telnet access

With the Unified controllers, the APs which come online will dynamically get their configuration from the controller when they establish the LWAPP tunnel.

When AP based feature are configured, such as AP provisioning or AP-based user authentication (de-central authentication), it can be useful to understand and see what is going on on the AP. The APs have a console port, but this console port cannot be used once the AP has established the LWAPP tunnel.

This post shows how the administrator can enable console and telnet access to the AP. Continue reading

Posted in Unified Wireless | Tagged , , | 1 Comment

Getting ready for next-gen IRF !

HP Comware switches have had IRF (Intelligent Resilient Framework) for years, and it was the basis of more simplified network topologies. Now it seems HP is preparing a next-generation of IRF !

Continue reading

Posted in Comware7, IRF | Tagged , | 4 Comments

HP Unified Wireless: R3507P22 includes Apple Bonjour gateway

HP has released firmware R3507P22 for the Unified wireless controller portfolio (830/850/870 appliance controllers and 20G module).

Sample of the 870 controller:

HP Unified wireless 870

Several new features have been included, 2 interesting new features are:

  • Support for vlan-pool at the AP-group configuration level
  • Includes an Apple Bonjour gateway proxy and filtering solution

Continue reading

Posted in Unified Wireless | Tagged , , , , , | 1 Comment

Always wanting to join new HPN Scripting GitHub community!!!!

Dear network community,

Last week HP had great ETSS event. As promised after my HPN Scripting session at ETSS I would launch the HPN-Scripting repository on GitHub (https://github.com/networkingdvi/HPN-Scripting). All the example scripts from the presentation are uploaded and scripts I received from Thomas Kubica and Chuck Dilts. From the repository you can download all the scripts you want and use them for your need. It would be really great if we get community that starts to actively be part of the GitHub and add scripts. Think about following topics:
– HPN TCL scripts
– HPN Python scripts
– Scripts to use on HPN infrastructure
– IMC eAPI scripts
– HPN SDN controller scripts
– Etc.

If you want to join and add value to this repository and start adding your scripts please provide me your GitHub username and you’ll be added as contributor.

Let’s make great community!!!

Looking forward for all your inputs!

Regards, Dobias van Ingen

Posted in Comware7, IMC Platform, Scripting, SDN | 2 Comments

HPN Scripting on Github

Dear network community,

Based on the feedback of Lindsay Hill on my last post I created a HPN Scripting GitHub repository. The repository is completely free with MIT license. After HP ETSS event next week I’ll post my scripts under this repository. The GitHub repository can be found via following URL:

HPN Scripting on GitHub

Let’s hope and try to drive this blog and repository to create HPN community that shares, supports and have fun.

Regards, Dobias van Ingen

E-mail: dobias.vaningen@gmail.com

Twitter: @networkingdvi



Posted in Comware7, IMC Platform, Scripting, SDN | 2 Comments

HP network scripting

Dear HP Network Community,

My name is Dobias van Ingen and I’m working within HP for almost 15 years. I’ve always been in networking and Unix / Linux infrastructures. Currently I’m leading an EMEA pre-sales overlay team with strong technical focus on HP Networking.  My comments, views and opinions are all my own and do not reflect those of my employer.

Multiple HP network devices provide support for API’s or scripting languages. Hereby a few examples: Continue reading

Posted in Comware7, IMC Platform, Scripting, SDN | Tagged , , , , , , | 5 Comments

6125XLG console/aux port access for IRF renumber

For HP Blade enclosures, the 6125XLG can be used as a non-blocking 10G blade server access switch with 4x40G uplink ports. Since it is based on Comware 7 (very similar to the 5900AF model, but in a blade switch form factor), 2x 6125XLG switches in the blade enclosure can be configured to operate in a single IRF system.

20140613-6125xlg-front









Continue reading

Posted in Uncategorized | Leave a comment

HP Unified Wireless: AP Based (decentral) 802.1x authentication

This is a follow-up on the post which shows the basic 802.1x authentication. Make sure to read that post first before continuing with the this local authentication article:

https://abouthpnetworking.com/2014/06/03/hp-unified-wireless-central-802-1x-configuration/

This post configuration will result in:

  • Decentral (local AP) authentication: AP forwards all 802.1x directly to the RADIUS server
  • Decentral (local AP breakout) forwarding: AP forwards all user data directly with a VLAN tag to the Switch Port connecting the AP

The post assumes you have completed the central 802.1x configuration already (see link above), so only additional changes to that configuration are listed here.

Continue reading

Posted in Unified Wireless | 2 Comments

HP Unified Wireless: Central 802.1x configuration

This post is a sample configuration of an 802.1x WPA2/AES WLAN service on the HP Unified Wireless platform.

This configuration assumes:

  • Central authentication: AP forwards all 802.1x over the LWAPP tunnel to the Access Controller (AC). The AC is the radius client
  • Central forwarding: AP forwards all user data over the LWAPP tunnel to the AC. the wired network will see the wireless mac address coming in from the AC switch port.

Continue reading

Posted in Unified Wireless | 10 Comments

HP Unified Wireless: Free access option on guest portal

This post covers a simple portal web interface customization, which will provide a “Free Access” option for guest users.

Some organizations do not want to administer guest accounts, but simply want to display a legal disclaimer which should be accepted and then allow internet access.

These are the basic configuration steps:

Continue reading

Posted in Unified Wireless | Tagged , , , | 7 Comments

HP Unified Wireless: Guest central authentication with data local breakout

In this post a quick configuration overview of a new feature of the Unified controllers:

Central (guest) portal authentication with local (AP) data breakout after passing authentication.

This is very convenient for customers with remote sites, where the remote site has a local internet connection but no wireless controller available. So they want to have a Guest SSID with a portal authentication (which will be centrally provided by the AC), and after a guest passes authentication, it will be assigned to a local-breakout VLAN. This means the (remote site) AP will directly put the guest into the local guest internet VLAN (after passing authentication).

Continue reading

Posted in Unified Wireless | 1 Comment

HP Unified Wireless: Portal authentication for extended Layer2 guest subnet

This post covers the HP Unified Wireless controller (AC) portal configuration in a scenario of an extended L2 guest subnet configuration.

There are 2 scenario’s to handle guest IP subnets:

  • A new IP subnet, where the AC is the default gateway, performs portal authentication and then routes/NATs the guest traffic to the internet.
  • An existing IP subnet, provided by an existing guest Internet router. The guest internet router will provide DHCP and NAT services for the guests. The AC just needs to provide portal authentication services. Guests who have passed portal authentication, will be L2 forwarded by the AC (not routed).

This post covers the second scenario: Extending the external internet router IP subnet as the guest subnet. Continue reading

Posted in Unified Wireless | Leave a comment
